2 point locking.
30 mm backset.
85 mm pitch.
Accepts fixed cam euro cylinder (not supplied).
Accepts 7.6 mm or 8 mm spindle.
Latch deadlocked with key.
12 mm latch bolt.
Supplied with 2 mm latch packer.
24 mm main bolt throw (selectable down to 13 mm).
Suits door thickness 32 to 45 mm.
Stainless steel face plate 210 x 24 mm.
Case size 180 x 45 mm.
Supplied less cylinder.
Supplied less strike plate.
Achieves Australian Standards AS 4145.2-2008 Security Level S7 and Durability Level D7

Lock status
Palladium (Xtra) Snib furniture is required in order to use the snib-lock function.

Passage mode
Passage mode gives convenient access from inside and outside without the need for a key.

Safety mode
Safety mode is activated and deactivated by operating the snib lever from inside and requires the key to unlock from outside.

Secure mode
Handles locked securely from both inside and outside and requires key to unlock from either side.
