AMC Mouse 09/P Dual Tech Built in EOL, Creep & 15kg Pet Imm

Product Code: AMMOUSE09P

Are you a tradesperson?

Get access to our best prices



Description

Dual technology detectors with an analysis system that takes into account the two most important changes that may occur during a movement: the speed and the intensity. With the simultaneous comparison of these two information, the detectors are able to discriminate repetitive movements from intrusion, lowering the percentage of false alarms.

With high thermal variations, the totally digital temperature compensation system, guarantees a great performance. Are equipped with internal EOL resistors.

They have 15 mt coverage, with angle of 90°. With the special lens are equipped of creep zone & 15kg Pet Immunity.

Technical Features Mouse 02 Mouse 09 Mouse 02/P Mouse 09/P
EN 50131-2-4 / Grade 2 - Yes - Yes
EN 50131-2-4 / Grade 3 Yes - Yes -
Range 15 mt 15 mt 15 mt 15 mt
Angle 90° 90° 90° 90°
Alarm Time 2 Sec 2 Sec 2 Sec 2 Sec
Self Test Yes - Yes -
Walk Test's LED Yes Yes Yes Yes
Microwave Frequency 9.3 - 9.9 - 10.5 Ghz 9.3 - 9.9 - 10.5 Ghz 9.3 - 9.9 - 10.5 Ghz 9.3 - 9.9 - 10.5 Ghz
Solid State Relay Yes Yes Yes Yes
Internal EOL Resistors 1k, 2k2, 4k7, 5k6, 8k2 1k, 2k2, 4k7, 5k6, 8k2 1k, 2k2, 4k7, 5k6, 8k2 1k, 2k2, 4k7, 5k6, 8k2
Creep Zone Yes Yes Yes Yes
Cover Tamper Yes Yes Yes Yes
AntiMasking Device Yes - Yes -
Pulse Counter Yes Yes Yes Yes
RFI Protection 30 V/m 30 V/m 30 V/m 30 V/m
Temperature Compensation Yes Yes Yes Yes
Digital Analysis Yes Yes Yes Yes
Bracket Available Yes Yes Yes Yes
Power Supply 13.8 Vdc 13.8 Vdc 13.8 Vdc 13.8 Vdc
Consumption 23 mA 23 mA 23 mA 23 mA
Pet Immunity - - Yes Yes
Operating Temperature -10°C to 40°C -10°C to 40°C -10°C to 40°C -10°C to 40°C
Dimensions 110 x 60 x 46 mm 110 x 60 x 46 mm 110 x 60 x 46 mm 110 x 60 x 46 mm
Technical Specifications
Brand AMC
Finish White
Type of Detector PIR with Creep & Pet Immunity
